8mm Mild Steel YAG Lamp Pump Laser Cutting Machine GJMSJG-8060DT manufacturer from China Wuhan Golden Laser CO., LTD.

8mm Mild Steel YAG Lamp Pump Laser Cutting Machine

Payment Terms:	T/T,L/C
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: GJMSJG-8060DT

Production Capacity: 4000 sets/year

Delivery Date: 15-30 working days

Laser Type: YAG

Means of Transport: FOB shanghai

Packing: Wooden Case Package

Application: Laser Cutting

Brand Name: GoldenLaser

1.Medium power lamp pump laser tube, it is able to cut any intricate graphics with high speed and high precision.

GJMSJG-8060DT 8mm Mild Steel YAG Lamp Pump Laser Cutting Machine

Metal Laser Cutting Machine Highlights:

Thick steel plate frame with strong deformation resistance ability, stable performance and nice appearance.
Medium power lamp pump laser tube, it is able to cut any intricate graphics with high speed and high precision. No need secondary treatment.
Dynamic focusing device for continuous and automatic focus cutting uneven material.
Universal wheel and pneumatic loading device for loading and unloading easily, saving labor power and avoiding material scratched.
Following bottom exhaust system, a very good air suction system, making the whole processing without fumes.
Digital operation panel and mobile controller, easy to use.
Advanced technologies of smart nesting, fast digitizing and auto-recognition ensure material saving and high efficiency.
Rotary attachment (integrated or detached type optional) for positioning punching, slotting and cutting metal pipes.
Stainless steel less than 6mm and mild steel less than 8mm, you can just use air to laser cut (no required oxygen gas). Good cutting effect, maximizing reducing use-cost.

Metal Laser Cutting Machine Applications:

Suitable for all kinds of precision cutting to metal sheet material, such as carbon steel, stainless steel, alloy steel, aluminum and alloys, copper and alloys, titanium and alloys, nickel-molybdenum alloys and so on.

Metal Laser Cutting Machine Technical Data:

Laser generator	YAG lamp pump laser tube
Laser power	500W
Cutting area	600mm×800mm
Working table	Net saw-teeth work table
No load max speed	0-30000mm/min
Repeating location	±0.15mm
Moving system	offline CNC system,servo motor,precision ball screw drive
Cooling system	18KW constant temperature water chiller
Power supply	Three phase 380V±5%/50/60HZ
Supporting format	PLT,DXF,BMP,AI,DST
Sdandard collocation	Following focus,1.1KW bottom exhaust
Select collocation	650W lamp pump
