Metal and Non-metal CO2 RF Laser Cutting in Machinery

Payment Terms:	T/T,L/C
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: JMSCJG-130250DT

Production Capacity: 4000 sets/year

Delivery Date: 15-30 working days

Laser Type: CO2

Means of Transport: FOB shanghai

Packing: Wooden Case Package

Application: Laser Cutting

Brand Name: GoldenLaser

1.It adopts steel girde structure
2.Precision ball screw drive and servo motor drive system bring you high cutting precision

JMSCJG-130250DT Metal and Non-metal CO2 RF Laser Cutting in Machinery

Laser Cutting Machinery Features:

1.It adopts steel girde structure

2.Precision ball screw drive and servo motor drive system bring you high cutting precision

3.400W CO2 RF metal laser tube produces good laser beam,stable power and long working life,low cost and maintenance free

4.The strip working table reduce the contacting area with work piece,which ensures high quality cutting

5.Following exhaust system has good performance,saving energy consumption for you

6.The smart nesting function enhances the utilization rate

7.The 5 inch CNC system provides online and offline for your choice,easy to use

8.Wide application,suitable for metal and non-metal cutting

Laser Cutting Machinery Applications:

Applicaion Materials:stainless steel,mild steel,acrylic,wood and other non-metal plates

Application Industry:metal plates working and Advertising and sign industry

Laser Cutting Machinery Technical Parameter:

Laser type

CO2 RF metal laser tube

Laser power

400W

Working area

1300mm*2500mm

Working table

Strip panel working table

Repeating location

±0.1mm

Cooling system

Constant temperature water chiller

Moving system

Servo motor,LCD display,ball screw driving system

Power supply

AC220V±5% / 50HZ

Support format

AI,BMP,PLT,DXF,DST etc

Standard collocation

Mini air compressor,auto control high pressure blow valve

Select collocation

200W,600W CO2 RF metal laser tube

Compared with traditional way of metal cutting,laser cutting have the following advantages:

1>None contact process

The low impact and load as none contact process,little or no heat damage at the workpieces

2>Smallest head attect zone

Improved parts production and reduced part distortion

3>Various cutting ability

Laser is suits for stainless steel,hardened steel,mild steel,cold rolled steel,copper,aluminum,brass, tungsten,titanium,alloy,galvanlized sheet,iron

4>Rapid esign change ability

Using laser could improved ability to perform rapid design changes due to the programming flexibility of laser machines

5>Narrow "kerf"

Enhanced intricate part cutting ability due to narrow "kert" width,also improved and efficient part nesting capability due to narrow “kert” width and programming flexibility

	Lamp Pump YAG	CO2 Laser	Fiber Laser
Cutting edge quality	Good	Good	Very Good
Material	Non-ferrous materials and ferrous steel	Ferrous steel and non-metal material	Metal
Power consumption	Medium	Low	Very Low
Consumption parts	Lamp,protection mirror	Gas	Low gas
Maintenance period	One week	One month	Maintenance free
Investment	Low	Medium	High
